FWT-60 Medium frequency inverter roll welding machine

Introduction of performance features:

1. A welding equipment designed for customers that can run continuously for a long time, especially suitable for automobile, household appliances and other product industries

2. Select alloy brush, choose silver alloy with thickness up to 3mm, high quality imported brush, extra large contact area, reduce heating and prolong service life;

3. Precision machining adopts CNC machine tool to process all parts to ensure the reliability and accuracy of each part;

4. Single wheel drive to ensure the same tangent speed of upper and lower wheels;

5. It is driven by three-phase stepless speed regulating electrode, and the welding speed can be adjusted conveniently and stably. internal structure can reduce welding performance weakening caused by heating.

Consult

Product Details

Introduction of performance features:

1. A welding equipment designed for customers that can run continuously for a long time, especially suitable for automobile, household appliances and other product industries

2. Select alloy brush, choose silver alloy with thickness up to 3mm, high quality imported brush, extra large contact area, reduce heating and prolong service life;

3. Precision machining adopts CNC machine tool to process all parts to ensure the reliability and accuracy of each part;

4. Single wheel drive to ensure the same tangent speed of upper and lower wheels;

5. It is driven by three-phase stepless speed regulating electrode, and the welding speed can be adjusted conveniently and stably.

6. The welding machine adopts the form of transverse welding, which is suitable for the welding needs of various workpieces.

7. Ingenious and reasonable internal structure can reduce welding performance weakening caused by heating.

8. The silver bearing bush is in good contact with rotation and conductivity to minimize the loss of electric energy conversion.

9. Widely used in metal manufacturing and processing industries such as hardware, household appliances, automobile, basin making, can making, etc.

10. It is required to install tooling platform to facilitate operation and discharge during welding

Technical parameters of medium frequency inverter type roll welding machine:

Item / model:	FWT-60
Rated power:	90KVA
Primary voltage:	380V
Working frequency:	1000HZ
Large short circuit current:	30000A
Welding speed:	0.6～4M/min
Electrode stroke:	50mm
Electrode pressure:	2.5KN
Motor power supply:	380V
Motor power:	90W
Cooling water flow:	30L/min
